Heidelberg SM102 Perfector
The Heidelberg Speedmaster 102 is the best perfecting press for your needs. With advancing technology, the perfecting press is consistent for quality, accurate prints for a variety of print projects.
A high-quality, efficient, and automated perfecting press
Our Heidelberg SM102 perfector is technologically advanced and designed for perfect prints. With reliable perfecting across many different formats, it is designed to meet various business needs. Advanced technologies eliminate common errors that occur throughout the perfecting process and after so that you get your prints the way you intended, in less time.
Advanced Automated Machinery
Intelligent automation is at the core of the SM102 Heidelberg Perfector. With automation, human error is significantly reduced. This streamlined process ultimately reduces errors during the printing process while ensuring exceptional print quality for all your print projects.
Reliable Accuracy and Quality
The perfecting device helps ensure accuracy throughout the perfecting process. It works to maintain scratch-free, markless sheets. Color softwares help make automatic adjustments to the images, ensuring more accuracy for your designs.
Highly Stable Printing Process
The preset feeder keeps the paper pile at the optimum position for perfecting and provides reliable sheet separation at every speed. Increasing efficiency and accuracy for your prints without damage.
The Heidelberg speedmaster SM102: bring commercial printing to a new level
The Heidelberg Speedmaster 102 perfecting press provides solutions throughout the entire production process. Automation ensures a high-quality print, every time from start to finish. See your designs come to life through a variety of different printed deliverables without delay.

Brochures

Manuals

Business Stationery
SM102 Heidelberg Perfector
-
Technical specifications
SM102 Heidelberg Perfector Technical Specifications
Printing stock
- Max. sheet size
Standard- 650mm×940mm
(25.59in×37.01in)
- 650mm×940mm
- With format extension (option)
- 720×1020 mm
(28.35in×40.16in)
- 720×1020 mm
- Min. sheet size
(straight printing)- 340mm×480mm
(13.39in×18.90in)
- 340mm×480mm
- Min. sheet size
(perfecting mode)- 400mm×480mm
(15.75in×18.90in)
- 400mm×480mm
- Max. print format
Standard- 640mm×920mm
(25.20in×36.22in)
- 640mm×920mm
- With format extension (option)
- 700mm×1,020mm
(27.56in×40.16in)
- 700mm×1,020mm
- Thickness
- 0.03mm–0.60mm
(0.0012in×0.024in)
- 0.03mm–0.60mm
- Gripper margin
- 10mm–12mm
(0.39in×0.47in)
- 10mm–12mm
Print output Speedmaster SM 102
- Maximum
- 14,000sph
Print output Speedmaster SM 102-10-P
- Maximum
- 13,000sph
Plate cylinder
- Cylinder undercut
- 0.12mm (0.005in)
- Distance from lead edge of plate
to lead edge of print- 43mm/52mm
(1.69in/2.05in)
- 43mm/52mm
Plates
- Length×width
Standard- 721mm×930 mm
(28.39in–36.61in)
- 721mm×930 mm
- With format extension (option)
- 790mm×1030 mm
(31.10in–40.55in)
- 790mm×1030 mm
- Thickness with AutoPlate
- 0.20mm–0.30mm
(0.008in–0.012in)
- 0.20mm–0.30mm
- Thickness with AutoPlate Pro
- 0.24mm–0.30mm
(0.009in–0.012in)
- 0.24mm–0.30mm
Blanket cylinder
- Length×width,
blanket (metal-barred)- 840mm×1,052mm
(33.07in×41.42in)
- 840mm×1,052mm
- Thickness
- 1.95mm (0.077in)
- Cylinder undercut
- 2.30mm (0.091in)
- Length×width,
packing sheet- 735mm×1,030mm
(28.94in×40.55in)
- 735mm×1,030mm
Pile heights
(incl. pile table and pile support plate)- Preset Plus feeder
- 1,320mm (51.97in)
- Preset Plus delivery
- 1,295mm (50.98in)
Sample configuration
- Basis: Speedmaster SM 102-8-P with Preset Plus feeder and Preset Plus delivery, without peripherals
- Number of printing units
- 8
- Length
- 15.95m (627.95in)
- Width
- 3.33m (131.10in)
- Height
- 2.15m (84.65in)
- Max. sheet size
